Kyoritsu 3166 Analogue Insulation Resistance Tester

Price:

$ 208.00

Kyoritsu 3166 Analogue Insulation Resistance Tester
  2. Shop
  3. Kyoritsu 3166 Analogue Insulation Resistance Tester
Kyoritsu 3165 Analogue Insulation Resistance Tester
Kyoritsu 3165 Analogue Insulation Resistance Tester
$ 201.00
$ 201.00
Kyoritsu 3431 Analogue Insulation Resistance Tester
Kyoritsu 3431 Analogue Insulation Resistance Tester
$ 434.00
$ 434.00

Kyoritsu 3166 Analogue Insulation Resistance Tester

https://www.etisupply.com/web/image/product.template/1058303/image_1920?unique=b43e63a

$ 208.00 208.0 USD $ 208.00

Not Available For Sale

($ 208.00 / Units)
  • Brand

This combination does not exist.

Contact Us
Kyoritsu


Terms and Conditions
Product images shown are for illustration purposes only and may not be an exact representation of the product.

ANALOG INSULATION TESTER

MODEL 3166

1000V/2000MΩ

  • 1000V/2000MΩ
  • Expanded megohm scale for easy reading
  • New robust housing case to prevent damage
  • AC voltmeter scale for easy reading

Specification

Insulation Resistance
DC Test Voltage1000V
Max. effective scale value2000MΩ
Mid-scale value50MΩ
First effective measuring range2 to 1000MΩ
Accuracy±5%rdg
Second effective measuring range1/2000MΩ
Accuracy±10%rdg
AC Voltage
AC Voltage600V
Accuracy±3% of full scale value
General
Power sourceR6 (AA) (1.5V) × 4
Dimension90(L) × 137(W) × 40(D)mm
WeightApprox. 330g
Accessories7025 (Test leads)
9074 (Cord case)
9123 (Shoulder strap)
R6 (AA) × 4
Instruction Manual
