Klein Ratcheting Heat Shrink Terminal Crimper, 10 to 22 AWG Wire (3007CR)
SKU: 3007CR
- Crimping tool crimps heat shrink terminals onto 10-22 AWG stranded copper wire
- Adjustable compound action design puts more crimping power into each squeeze
- Three crimping cavities in one tool: 22–16 AWG (Red), 16–14 AWG (Blue) and 12–10 AWG (Yellow) terminals
- Built-in ratchet ensures full-cycle crimping for a uniform crimp every time
- Unique cavity design provides consistent crimp from either side of the tool
- Dial adjusts the amount of force applied to the crimp
- Dual-material molded grips provide added comfort
3007CR
Ratcheting Heat Shrink Terminal Crimper, 10 to 22 AWG Wire
The full-cycle Ratcheting Crimper crimps 10-22 AWG heat shrink wire terminals. This tool features three crimping cavities in one tool with color-coded wire markings for three size ranges of heat shrink terminals. Crimper design provides low effort to crimp while maintaining a high terminal pull-off force. Built-in ratchet ensures full-cycle crimping for a uniform crimp every time.
Specifications
- Application: Heat-Shrink Terminal Crimping on Stranded Wire
- Type: Ratcheting Crimper
- Handle Color: Red/Black
- Connector Type: Heat Shrink
- Special Features: 3 Crimping Cavities
- Material: Steel
- Cable Size: 10-22 AWG
- Handle Finish: Dual-Material
- Crimps: Yes
- Strips: No
- Cuts: No
- Style: Heat Shrink Terminals
- Weight: 1.3 lb
- Overall Height: 0.09 in (0.2 cm)
- Overall Length: 9 in (22.9 cm)
- Overall Width: 3 in (7.6 cm)
- UPC: 092644340581
Additional Information
Warnings
- Always wear approved eye protection.
- NOT insulated. Plastic-dipped or slip-on plastic handles are NOT intended for protection against electrical shock.
| Brand | Klein Tools |
