Stahlwille 1/2" Drive Torque Wrench MANOSKOP® 730R/20 Quick 40–200 Nm / 30–145 ft-lb (96504020)

Price:

$ 798.05

Stahlwille 1/2" Drive Torque Wrench MANOSKOP® 730R/20 Quick 40–200 Nm / 30–145 ft-lb (96504020)
  2. Shop
  3. 1/2" Drive
  4. Stahlwille 1/2" Drive Torque Wrench MANOSKOP® 730R/20 Quick 40–200 Nm / 30–145 ft-lb (96504020)
Stahlwille 1/4" Drive Torque Wrench MANOSKOP® 730R/2-1 QUICK 2-10 Nm (96501054)
Stahlwille 1/4" Drive Torque Wrench MANOSKOP® 730R/2-1 QUICK 2-10 Nm (96501054)
$ 871.30
$ 871.30
Stahlwille 3/4" Drive Torque Wrench MANOSKOP® 730R/40 Quick 80–400 Nm / 60–300 ft-lb (96504040)
Stahlwille 3/4" Drive Torque Wrench MANOSKOP® 730R/40 Quick 80–400 Nm / 60–300 ft-lb (96504040)
$ 1,318.15
$ 1,318.15

Stahlwille 1/2" Drive Torque Wrench MANOSKOP® 730R/20 Quick 40–200 Nm / 30–145 ft-lb (96504020)

https://www.etisupply.com/web/image/product.template/358452/image_1920?unique=4115969

SKU: 96504020

  • Locking lever for quick, precise torque adjustment
  • No reset to "0" required — low-wear bending beam release system
  • Dual scale Nm / ft-lb
  • Clicking type with dual stop signal
  • Accuracy ±4%; calibration certificate per DIN EN ISO 6789-2:2017
  • 1/2" square drive; 14 x 18 mm insert tool holder; measuring range 40–200 Nm (30–145 ft-lb)
  • QuickRelease safety lock; 2-component non-slip handle
  • Made in Germany — MANOSKOP® 730R Quick

$ 798.05 798.050438 USD $ 798.05 $ 1,064.07

Not Available For Sale

($ 0.00 / Units)
  • Brand

This combination does not exist.

locking lever no reset to 0 MANOSKOP® DIN EN ISO 6789-2:2017 30–145 ft-lb 40-200 Nm Stahlwille 1/2" Drive
Contact Us
Stahlwille


Terms and Conditions
Product images shown are for illustration purposes only and may not be an exact representation of the product.

96504020

Stahlwille 1/2" Drive Torque Wrench MANOSKOP® 730R/20 Quick 40–200 Nm (30–145 ft-lb)

Stahlwille MANOSKOP® 730R Quick setting torque wrench with holder for interchangeable insert tools. Patented low-wear flexible-rod release system — no reset to "0" after use. Quick adjustment via locking lever in the handle with dual Nm / ft-lb scale. Supplied with calibration certificate (DIN EN ISO 6789-2:2017). Accuracy ±4%.

Specifications

  • Product no.: 96504020
  • Size: 20
  • Model: 730R Quick
  • Measuring range: 40–200 Nm (30–145 ft-lb)
  • MA Nm: 40 Nm
  • Nominal value Nm: 200 Nm
  • Scale division Nm: 5 Nm
  • Scale division ft-lb: 5 ft-lb
  • Tool holder size: 14 x 18 mm
  • External square drive (inch): 1/2
  • Length mm (L): 530 mm
  • b1: 55 mm
  • b2: 43 mm
  • Height mm (h): 55 mm
  • LF: 435 mm
  • SF: 25 mm
  • Weight: 1626 g (1.626 kg / 3.58 lb)
