Stahlwille 9x12 mm Insert Torque Wrench MANOSKOP® 730N/10 FIX 20–100 Nm / 15–75 ft-lb (96503010)

SKU: 96503010 | 730N/10 FIX

EAN: 4018754269440

  • Type: Click-type service torque wrench with dual stop signal
  • Series / Model: MANOSKOP® 730N FIX, Size 10
  • Application: Assembly-line / repetitive production tasks
  • Tool Holder: 9 x 12 mm (interchangeable insert tools)
  • Torque Range: 20–100 Nm / 15–75 ft-lb
  • Nominal Value: 100 Nm
  • Minimum Setting (MA): 20 Nm
  • Accuracy: ±3%
  • Standard: DIN EN ISO 6789-2:2017
  • Tightening Direction: Clockwise and counterclockwise (reverse insert tool)
  • Scale: Dual scale N·m / ft·lb with color differentiation
  • Trigger: Mechanical click with audible and tactile dual stop signal
  • After-click / reverse load: Does not affect trigger mechanism (protected)
  • Adjustment: QuickSelect rapid adjustment; knob can be removed after setting to prevent accidental changes
  • Tamper protection: Includes TORX® Tamper Resistant locking screw and adhesive seals

Technologies and features

  • QuickRelease
    The QuickRelease safety lock prevents unintentional loss of sockets and insert tools. These click securely into place and are only released again at the push of a button for a quick tool change.
  • Low-wear bending beam system
    Equipped with a low-wear release system using a bending beam. Unlike conventional torque wrenches with coiled springs, the bending beam is not subjected to any load until the tool is in operation, so resetting to “0” is not necessary after use.
  • Adjustment Lock
    The target torque can be quickly adjusted using the adjustment knob. The knob can then be removed to prevent subsequent adjustment. The supplied TORX® Tamper Resistant locking screw and adhesive seal provide additional protection against tampering.
  • 2-component handle
    Non-slip and ergonomically designed. Resistant to the most common oils, greases, fuels, brake fluids, and Skydrol. Arrow markings on the handle indicate the direction of operation.
  • DIN EN ISO 6789-2
    Professionally calibrated in accordance with DIN EN ISO 6789-2 and delivered with a corresponding calibration certificate. Ensures accuracy and traceability.
  • QuickSelect
    Lightning-fast target value setting: Unlock the adjustment knob, set the value, and lock the knob again.

Properties

  • For work on assembly lines or for repetitive production tasks
  • Clicking type with dual stop signal
  • Adjustment knob can be unscrewed after setting the desired torque value — subsequent changing of the setting is thus prevented
  • The included TORX® Tamper Resistant locking screw and self-adhesive seals protect against tampering; no adjustment is possible without breaking the seal
  • No reset to “0” required
  • The measuring element is only under load when a force is applied
  • Fast, precise adjustment with QuickSelect
  • Dual scale N·m / ft·lb
  • Mount for interchangeable insert tools
  • With QuickRelease safety lock
  • Clicking mechanism insensitive to continuous loads and counter-loads (up to the max. measurement range)
  • Counter-clockwise tightening by turning the insert tools over
  • Optimal calibration with perfectControl® calibration systems No. 7794 or calibration systems No. 7706 / 7791
  • Easy adjustment without disassembly via 2 external adjustment screws
  • With 2-component handle
  • Supplied in sturdy plastic box
  • Calibration certificate in accordance with DIN EN ISO 6789-2:2017
  • Accuracy ±3%

Specifications

  • Overall Length (L): 386 mm
  • Width (b): 28 mm
  • Height (h): 23 mm
  • Calibration Length (LF): 336 mm
  • SF: 17.5 mm
  • Weight: approx. 988 g
  • Insert tools not included
  • Supplied in sturdy plastic box with calibration certificate
  • Made in Germany

Note: Technical changes and errors reserved.
