Stahlwille 22x28 mm Insert Torque Wrench MANOSKOP® 730N/100 200-1000 Nm / 150-750 ft-lb (50181100)

Price:

$ 2,573.69

Stahlwille 22x28 mm Insert Torque Wrench MANOSKOP® 730N/100 200-1000 Nm / 150-750 ft-lb (50181100)
  2. Shop
  3. Torque Wrenches
  4. Stahlwille 22x28 mm Insert Torque Wrench MANOSKOP® 730N/100 200-1000 Nm / 150-750 ft-lb (50181100)
Stahlwille 9x12 mm Insert Torque Wrench MANOSKOP® 730N/10 20-100 Nm / 15-75 ft-lb (50181010)
Stahlwille 9x12 mm Insert Torque Wrench MANOSKOP® 730N/10 20-100 Nm / 15-75 ft-lb (50181010)
$ 641.76
$ 641.76
Stahwille 14x18 mm Insert Torque Wrench MANOSKOP® 730N/12 25-130 Nm / 20-95 ft-lb (50181012)
Stahwille 14x18 mm Insert Torque Wrench MANOSKOP® 730N/12 25-130 Nm / 20-95 ft-lb (50181012)
$ 678.88
$ 678.88

Stahlwille 22x28 mm Insert Torque Wrench MANOSKOP® 730N/100 200-1000 Nm / 150-750 ft-lb (50181100)

https://www.etisupply.com/web/image/product.template/356877/image_1920?unique=47ec7bc

SKU: 50181100

  • Rotary knob (QuickSelect) for precise torque setting
  • No reset to "0" required — low-wear bending beam release system
  • Dual scale Nm / ft-lb
  • Clicking type with dual stop signal
  • Accuracy ±3%; calibration certificate per DIN EN ISO 6789-2:2017
  • 22 x 28 mm insert tool holder; measuring range 200–1000 Nm (150–750 ft-lb)
  • QuickRelease safety lock; 2-component non-slip handle
  • Made in Germany — MANOSKOP® 730N

$ 2,573.69 2573.6919 USD $ 2,573.69 $ 3,431.59

Not Available For Sale

($ 0.00 / Units)
  • Brand

This combination does not exist.

Insert Tool 22x28 no reset to 0 MANOSKOP® DIN EN ISO 6789-2:2017 150–750 ft-lb 200-1000 Nm Stahlwille
Contact Us
Stahlwille


Terms and Conditions
Product images shown are for illustration purposes only and may not be an exact representation of the product.

50181100

Stahlwille 22x28 mm Insert Torque Wrench MANOSKOP® 730N/100 200–1000 Nm (150–750 ft-lb)

Stahlwille MANOSKOP® 730N service torque wrench with holder for interchangeable insert tools. Patented low-wear bending-beam release system — no reset to "0" after use. Precise torque setting via rotary knob (QuickSelect) with dual Nm / ft-lb scale. Supplied with calibration certificate (DIN EN ISO 6789-2:2017). Accuracy ±3%.

Specifications

  • Product no.: 50181100
  • Size: 100
  • Model: 730N
  • Measuring range: 200–1000 Nm (150–750 ft-lb)
  • MA Nm: 200 Nm
  • Nominal value Nm: 1000 Nm
  • Scale division Nm: 100 Nm
  • Scale division ft-lb: 25 ft-lb
  • Fine scale division: 5 Nm
  • Tool holder size: 22 x 28 mm
  • Length mm (L): 1363 mm
  • Width mm (b): 30.6 mm
  • Height mm (h): 25.6 mm
  • LF: 1352 mm
  • SF: 55 mm
  • Weight: 5000 g (5.000 kg / 11.02 lb)
