10 3/4" Digital Crimping Pliers - Four-Mandrel For Turned Contacts

97 52 65 DG

•  Four mandrel crimping pliers for turned contacts
•  For crimping turned contacts
•  Capacity - 0.14 to 6 mm² and 26 to 10 AWG
•  Four-mandrel crimping for top-quality crimping connections
•  Mandrel gauge to check the basic setting
•  Repetitive, high crimping quality due to integral lock (self-releasing mechanism)
•  Optimum transmission of force due to highly effective lever action for fatigue-reduced operation
•  Comfortable multi-component grips
•  Crimping capacity can be adjusted in increments of .0004" (0.01 mm); with digital display of the preset crimping capacities; adjustment in mm, inches or comparable selection positions according to MIL; with table for calculating the settings; packaged in a plastic case with foam insert and locator for holding the contacts
•  Chrome vanadium electric steel in special quality; oil-hardened

Technical details

• Part Number: 97 52 65 DG
• UPC: 843221015916
• Country of Origin: Germany
• Length: 10 3/4"
• Width: 8 7/8"
• Height: 3 3/8"
• Weight: 2.795 lbs.
• 1000 Volt Insulated: No
• Spring Loaded: Yes
• Material Type: Chrome vanadium electric steel, oil-hardened
• Handle Type: Multi-component
• Other Surface Finish: Chrome Plated
• Crimping Profile: Four-Mandrel crimp
• Crimping Positions: 1
• Color: Red/Blue
• Reach: contains SVHC
• RoHS: not applicable

Warnings:

• Do not use on live circuits. Always switch off power.
• Always wear approved eye protection.

Note: Technical changes and errors reserved.
