12" Pliers Wrench

86 01 300

•  Replaces a full set of inch and metric open end wrenches up to 2 1/2" (68 mm)
•  Smooth jaws for damage free installation of plated fittings - working directly on chrome
•  Adjustable tightening tool
•  Excellent for gripping, holding, pressing and bending applications
•  Zero backlash jaw surface pressure prevents damage to edges of sensitive components
•  24 adjustment positions at the touch of a button directly on the workpiece
•  Laser-etched scale allows the wrench opening to be set before gripping onto workpiece - metric and inch markings
•  Parallel jaws allow infinitely variable gripping of all widths to the specified maximum size
•  Reliable catching of the hinge bolt: no unintentional shifting
•  Chrome vanadium electric steel; forged, oil-hardened
•  Lever transmission greater than 10-1 for strong gripping power
•  The action of the jaws allows bolted connections to be tightened and released quickly using the ratchet principle

Technical details

• Part Number: 86 01 300
• UPC: 843221027650
• Country of Origin: Germany
• Length: 12"
• Width: 2 1/4"
• Height: 5/8"
• Weight: 1.6 lbs.
• 1000 Volt Insulated: No
• ESD Indicator: No
• Spring Loaded: No
• Material Type: Chrome vanadium electric steel, forged, oil-hardened
• Handle Type: Non-slip plastic
• Gripping Surface: Smooth
• Surface Finish: Polished
• Other Surface Finish: Black atramentized
• Joint Type: Box-joint
• Number of Adjustment Positions: 24
• Jaw Length: 1 9/32"
• Jaw Thickness: 35/64"
• Tip Thickness: 29/64"
• Max Jaw Opening - Hex: 2 1/2"
• Max Jaw Opening - Working Capacity: 2 1/2"
• Color: Red
• Handle Width: 2 1/4"
• Reach: does not contain SVHC
• RoHS: not applicable
• Reach: does not contain SVHC
• RoHS: not applicable

Warnings:

• Do not use on live circuits. Always switch off power.
• Always wear approved eye protection.

Note: Technical changes and errors reserved.
