High Leverage Diagonal Cutters

74 01 180

• For very tough, continuous use
• High cutting performance with minimum effort due to optimum coordination of cutting edge angle and transmission ratio
• Precision cutting edges induction-hardened (approx. 64 HRC) for all types of wire including piano wire
• Chrome vanadium heavy-duty steel, forged, multi-stage oil-hardened
• Forged-in axle for heavy-duty applications
• Approx. 20% less effort required compared to conventional diagonal cutters of the same size

Technical details

• Part Number: 74 01 180
• UPC: 843221001926
• EAN: 4003773022008
• Country of Origin: Germany
• Length: 7 1/4" (180 mm)
• Width: approx. 2"
• Height: 5/8"
• Weight: 0.53 lbs. (241 g)
• 1000 Volt Insulated: No
• Material Type: Chrome vanadium heavy-duty steel, forged, oil-hardened
• Handle Type: Plastic coating
• Surface Finish: Polished
• Other Surface Finish: Black atramentized
• Joint Type: Forged-in axle
• Cutting Capacity – Medium Hard Wire (Nail): 5/32" (3.8 mm)
• Cutting Capacity – Hard Wire (Steel Wire): 7/64" (2.7 mm)
• Cutting Capacity – Piano Wire: 3/32" (2.2 mm)
• Cutting Edge Shape: Bevel
• Color: Red
• DIN: DIN ISO 5749
• Reach: does not contain SVHC
• RoHS: not applicable

Warnings:

• Do not use on live circuits. Always switch off power.
• Always wear approved eye protection.

Note: Technical changes and errors reserved.
