Electronic torque wrench E-torc Q 20-200 Nm SE 14x18

ETQ 200

Code no.: 2958775 EAN: 4002805935606

Product description

  • Use: Controlled screw tightening and quality analysis in the range of 20-200 Nm
  • Type: Electronic torque and angle wrench with rectangular cavity for assembly, series production, quality control, maintenance and repair, and bolting case analysis

Features

  • All common measuring methods: torque, torque/angle of rotation, loosen-tighten, further tightening, yield point
  • Measurement accuracy: ± 1% of reading, ± 1 digit (torque); ± 1%, min. ± 1° on 360° at min. 4°/sec (angle)
  • Factory calibration certificate according to DIN ISO 6789 Type I Class C
  • Calibration certificate DAkkS DKD-R 3-7 Class 1 (optional)
  • Large TFT graphic display, 109 mm (4.3") diagonal; curve display and evaluation directly on the device
  • Operation via touch function or hardware keys
  • Housing rotatable by 60°
  • Powerful lithium-ion battery with quick-release system
  • Data management in XML format
  • Interfaces: WLAN (2.4 and 5 GHz) and USB mini
  • Internal memory for up to 9,999 measurement logs and curves
  • Free evaluation PC software included
  • Programmable with different gauges for insertion tools
  • 2D scanner optional

Dimensions and weights

  • Total width: 79 mm
  • Total height: 42.5 mm
  • Total length: 615 mm
  • Weight: 2.22 kg (4.9 lbs)
  • Head width: 33.0 mm
  • Distance middle of handgrip to pivot point: 552 mm

Scope of delivery

  • Electronic torque wrench E-torc Q
  • Battery ETQ APW
  • USB cable
  • Quadropak / plastic case

Technical characteristics

  • Drive type/drive: Rectangular cavity
  • Drive connector rectangular: 14 x 18 mm
  • Tightening direction: Left and right
  • Torque (max.): 200 Nm
  • Torque (min.): 20 Nm
  • Graphic display: Yes
  • Evaluation software: Yes
  • Interface: USB / WLAN
  • Precision: +/- 1%
  • Test certificate: DIN ISO 6789 Type I Class C

Note: Technical changes and errors reserved.

Brand Gedore Tools
