Torque wrench DREMASTER K 3/4" 80-400 Nm / 60-300 ft-lb

DMK 400

Code no.: 2641267 EAN: 4002805931400

Product description

• Use: Controlled screw tightening in the range of 80-400 Nm / 60-300 lbf·ft
• Type: Adjustable, releasing and sturdy tubular torque wrench with integrated ratchet and square drive for industry and the trades

Features

• Classified according to DIN EN ISO 6789-2:2017 Type II Class A, incl. traceable test certificate, calibrated to a maximum permissible deviation of +/- 3% and thus more precise than the +/- 4% required by the standard
• For controlled bi-directional tightening
• From model DMK 400: 3/4" push-through square and pin-locking mechanism
• Sturdy, varnished tubular steel construction, with zinc-plated ratchet head and top-grade plastic parts
• Ergonomically shaped plastic handgrip with calibration aid
• Change-over between Nm main scale and lbf·ft ancillary scale to avoid reading errors when setting the torque wanted
• With micrometre scale for main Nm scale for setting interim values
• Release system triggers a tactile and audible signal
• Ergonomic system for torque adjustment with reference symbol
• Secured adjusting/setting system

Dimensions and weights

• Total length: 714.8 mm
• Weight: 2.488 kg

Scope of delivery

• Storage/Content: Cardboard
• Contents (Qty of pieces): 1

Technical characteristics

• Drive type/drive: Square drive (male)
• Drive connector square: 3/4" (20.0 mm)
• Tightening direction: Left and right
• Trigger mechanism: Short path triggering
• Torque (max.): 300 lbf·ft / 400 Nm
• Torque (min.): 60 lbf·ft / 80 Nm
• Torque wrench function: Triggering
• Calibration length: 608.9 mm
• Distance housing - drive: 46 mm
• Head height: 38.0 mm
• Head width: 67 mm
• Material: Steel tube (construction), Plastic
• Vernier Nm: 1 Nm
• Precision: +/- 3%
• Test certificate: DIN EN ISO 6789-2:2017
• Graduation: 10 lbf·ft
• Scale division: 10 Nm

Note: Technical changes and errors reserved.
