Fluke 179 True-RMS Digital Multimeter (FLUKE-179)
SKU: 1564549 | 179
- 1000V AC/DC; 10A AC/DC (with test leads and current jacks); resistance to 50 MΩ; capacitance to 10,000 μF, frequency to 100 kHz; temperature from -40 ℃ to 400 ℃
- Robust, fast and accurate with manual and automatic ranging, Display Hold, Auto Hold, and Min/Max-Average recording
- Backlit digital display, analog bar graph, and built-in temperature measurements with included thermocouple.
What's in the box:
- 80BK Temperature Probe
- Installed 9V battery
- Test leads
- Users manual
179
Fluke 179 True-RMS Digital Multimeter (FLUKE-179)
Details
The Fluke 179 True-rms Digital Multimeter is the industry-standard troubleshooting tool for electrical and electronic systems. This incredibly versatile multimeter makes a perfect front-line troubleshooting tool with an input protection rating of CAT III 1000 V, CAT IV 600 V. The built-in temperature measurement with the included thermocouple, analog bar graph and backlit digital display make it easier to take the measurements you need.
A full set of basic and advanced troubleshooting capabilities including:
- Manual and automatic ranging
- Display Hold and Auto Hold
- Min/Max-Average recording
- Voltage measurements to 1000 V AC or DC
- Current measurements to 10 A AC/DC
- Resistance to 50 MΩ; capacitance to 10,000 μF, frequency to 100 kHz; temperature from -40 ℃ to 400 ℃
All of these features come paired with a lifetime warranty.
For a complete comparison of specifications, please visit our selection guide for digital multimeters.
| Fluke 179 True-RMS Digital Multimeter | Fluke 87V Industrial Multimeter | Fluke 287 True-RMS Electronics Logging Multimeter | Fluke 233 Remote Display Digital Multimeter | Fluke 3000 FC Series Wireless Multimeter | |
|---|---|---|---|---|---|
| CAT rating | CAT III 1000 V CAT IV 600 V | CAT III 1000 V CAT IV 600 V | CAT III 1000 V CAT IV 600 V | CAT III 1000 V CAT IV 600 V | CAT III 1000 V CAT IV 600 V |
| True-rms readings | ✔ | ✔ | ✔ | ✔ | ✔ |
| Voltage AC/DC | 1000 V | 1000 V | 1000 V | 1000 V | 1000 V |
| Current AC/DC | 10 A | 10 A | 10 A | 10 A | 400 mA |
| Resistance | 50 MΩ | 50 MΩ | 500 MΩ | 40 MΩ | 50 MΩ |
| Capacitance | 9,999 μF | 9,999 μF | 100,000 µF | 9,999 μF | 9,999 μF |
| Temperature | -40 °C to 400 °F | -200 °C to 1090 °C | -200 °C to 1350 °C | -40 °C to 400 °F | with t3000 FC |
| Additional measurement capabilities | Continuity/diode test, frequency, microamps | Frequency, continuity/diode test, motor drive (VFD) measurement, duty cycle, microamps, analog bar graph, relative reference | Conductance (50 ns), continuity/diode test, duty cycle, frequency, pulse width | Continuity/diode test, frequency | Frequency, continuity/diode test. Able to connect to three 3000 FC modules. |
What's in the box:
- 179 Digital Multimeter
- 80BK Temperature Probe
- Installed 9V battery
- Test leads
- Quick Reference Guide
Key Features
- 1000V AC/DC; 10A AC/DC (with test leads and current jacks); resistance to 50 MΩ; capacitance to 10,000 μF, frequency to 100 kHz; temperature from -40 ℃ to 400 ℃
- Robust, fast and accurate with manual and automatic ranging, Display Hold, Auto Hold, and Min/Max-Average recording
- Backlit digital display, analog bar graph, and built-in temperature measurements with included thermocouple.
Specifications
- Voltage DC - Accuracy 1: ±(0.09% + 2)
- Voltage DC - Max. resolution: 0.1 mV
- Voltage DC - Maximum: 1000 V
- Voltage AC - Accuracy 1: ±(1.0% + 3)
- Voltage AC - Max. resolution: 0.1 mV
- Voltage AC - Maximum: 1000 V
- Current DC - Accuracy 1: ±(1.0% + 3)
- Current DC - Max. resolution: 0.01 mA
- Current DC - Maximum: 10 A
- Current AC - Accuracy 1: ±(1.5% + 3)
- Current AC - Max. resolution: 0.01 mA
- Current AC - Maximum: 10 A
- Resistance - Accuracy 1: ±(0.9% + 1)
- Resistance - Max. resolution: 0.1 Ω
- Resistance - Maximum: 50 MΩ
- Capacitance - Accuracy 1: ±(1.2% + 2)
- Capacitance - Max. resolution: 1 nF
- Capacitance - Maximum: 10,000 µF
- Frequency - Accuracy 1: ±(0.1% + 1)
- Frequency - Max. resolution: 0.01 Hz
- Frequency - Maximum: 100 kHz
- Temperature - Accuracy 1: ±(1.0% + 10)
- Temperature - Max. resolution: 0.1°C
- Temperature - Range: -40°C / 400°C
1. Accuracies are best accuracies for each function
Environmental Specifications
- Operating temperature: -10°C to +50°C
- Storage temperature: -30°C to +60°C
- Humidity (without condensation): 0% – 90% (0°C – 35°C); 0% – 70% (35°C – 50°C)
Safety Specifications
- Overvoltage category: EN 61010–1 to 1000 V CAT III; EN 61010–1 to 600 V CAT IV
- Agency approvals: UL, CSA, TÜV listed and VDE Pending
Mechanical and General Specifications
- Size: 43 x 90 x 185 mm
- Weight: 420 g
- Warranty: Lifetime
- Battery life: Alkaline ~200 hours typical, without backlight
Additional Information
| Brand | Fluke |
175-177-179-Calibration-Manual-FLK_1564549.pdf
Download
175-177-179-Quick-Reference-Guide-Quick-Reference-Guide-FLK_1564549.pdf
Download
175-177-179-Safety-Sheet-FLK_1564549.pdf
Download
175-177-179-Users-Manual-FLK_1564549.pdf
Download
Fluke-170-Series-True-rms-Dmms-Technical-Data-FLK_1564549.pdf
Download
