Part No: US232R-10-BULK

USB to RS232 Serial Premium Cable w/ Embedded Electronics, LEDs, DB9M Conn, 10cm

USB to RS232 adaptor cable with TXD/RXD LEDs

• Data Rates: 1MBaud
• USB Speed: Full Speed (12Mbps)
• Interfaces: UART
• USB Connector: Type A
• End Connector: Male DB9
• Cable Length: 0.1m
• Cable Details: 4 core
• Packages: N/A
• Channels: 1
• I/O Voltage: RS232
• USB Class: FTDI Drivers
• Virtual Com Port: Yes
• Max Power Output: -
• FTDI Internal IC: FT232R
• Operating Temperature: -20°C to +80°C

 Documentation

• US232R-10 Cable

(Replacement part for US232B/LC)

The US232R-10 is FTDI’s premium 10cm USB to RS232 converter cable suitable for connecting RS232 legacy devices to a PC

The electronics, including the FT232RQ chip are housed in an attractive glossy white enclosure with blue, side-lit LED TX and RX traffic indicators. The white 1m USB cable uses gold plated USB and DB9 connectors.

Driver support is available for Windows, Apple Mac OSX, Linux and Android

The US232R-100 uses an enhanced RS232 level converter and is capable of communication rates from 300 baud to 1M baud.

The US232R-10 is fully RoHS compliant and is CE, FCC and UKCA approved.

Note: Shipment might be in bulk/blister package.
