Eaton FAZ-C7/3-RT branch protector, UL 1077 Industrial miniature circuit breaker
supplementary protector, medium levels of inrush current are expected, 7 A, 15 kAIC, Three-pole, 277/480 V, 5-10X /n, 50-60 Hz, Ring-tongue terminals, C Curve
General specifications
Product NameEaton FAZ branch protectorCatalog NumberFAZ-C7/3-RTEAN4015081021611Product Length/Depth2.07 inProduct Height4.25 inProduct Width2.25 inProduct Weight0.75 lbWarranty1 yearCertificationsCSA Std. C22.2 No.235
IEC 60947-2
UL 1077Catalog NotesPositioned for medium inrush startup currents to provide protection for small transformers and pilot devices.
Physical Attributes
Number of polesThree-poleTerminalsRing-tongueTypeUL 1077 Industrial miniature circuit breaker - supplementary protector
Performance Ratings
Amperage Rating7 ACircuit protectionC curveFrequency rating50-60 HzInterrupt rating15 kAICTrip Type5-10X /nVoltage rating277/480V
Miscellaneous
ApplicationSuitable for applications where medium levels of inrush current are expected
