Eaton FAZ-C7/2-RT branch protector, UL 1077 Industrial miniature circuit breaker
supplementary protector, medium levels of inrush current are expected,7 A,15 kAIC, Two-pole, 277/480 V, 5-10X /n, 50-60 Hz, Ring-tongue terminals, C Curve
General specifications
Product NameEaton FAZ branch protectorCatalog NumberFAZ-C7/2-RTEAN4015081020812Product Length/Depth1.38 inProduct Height2.5 inProduct Width4 inProduct Weight0.92 lbWarranty1 yearCertificationsIEC 60947-2
CSA Std. C22.2 No.235
UL 1077Catalog NotesPositioned for medium inrush startup currents to provide protection for small transformers and pilot devices.
Physical Attributes
Number of polesTwo-poleTerminalsRing-tongueTypeUL 1077 Industrial miniature circuit breaker - supplementary protector
Performance Ratings
Amperage Rating7 ACircuit protectionC curveFrequency rating50-60 HzInterrupt rating15 kAICTrip Type5-10X /nVoltage rating277/480V
Miscellaneous
ApplicationSuitable for applications where medium levels of inrush current are expected
