Model MN94 | Cat. #2140.81

AC Current Probe Model MN94 for Models PEL 52, 112, 113 & 115, and PowerPad ® IV 8345

Small and compact, the MN94 clamp is a current clamp for measuring AC current without disconnecting the circuit to take measurements.

The MN 94 clamp measures commerical power frequencies up to 200 A with a class 0.2 accuracy. Its excellent accuracy (gain and phase) make it ideal for current measurements with power and energy analyzers. In particular, it can be used to check electrical meters.

A key feature is the lead for the output signal is equipped with a molded 4-pin connector compatible with all PEL models (52, 112, 113 & 115) and the latest-generation PowerPad ® IV Class A model 8345.

Specifications

  • Maximum Conductor Size: 0.25" (16 mm)
  • Current Range: 50 mA 200 AAC
  • Frequency Range: (48 to 65) Hz
  • Dimensions (H x W x D): (5.12 x 1.81 x 1.34) in (130 x 46 x 34) mm
  • Sensor length: 10 ft (3 m)
  • Type of current sensor: Type A
  • Operating Temperature: (14 to 131) °F (-10 to 55) °C
  • Storage Temperature: (-40 to 158) °F ( -40 to 70) °C
  • Operating Humidity: (10 to 85) % RH
  • Storage Humidity: (10 to 90) % RH
  • Double Insulated: Yes
  • Ingress Protection (Ip): IP20
  • Pollution Degree: 2
  • Electromagnetic Compatibility (EMC): EN/IEC 61326-1
  • Safety Compliance: EN/IEC 61010-2-032 600 V CAT III , 300 V CAT IV
  • Warranty: 2 Years
  • Weight: 0.55 lb (0.25 kg)
